Power/Trigger/Strobe Cable for GigE cameras with Hirose connector HR10A-10P-12S to Flying Leads 2meters
Product Details:
| Place of Origin: | China |
|---|---|
| Brand Name: | DHT |
| Certification: | CE/ROHS/FCC/SGS/UL |
| Model Number: | CCXC-02SR |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100pcs |
|---|---|
| Price: | negotiation |
| Packaging Details: | 1 piece per PE Bag then 20pcs per carton |
| Delivery Time: | 3 - 7 working days |
| Payment Terms: | T/T or Paypal |
| Supply Ability: | 300,000pcs per month |
Detailed Product Description
| Product Name: | Camera Link Cable | Application: | CCD Camera |
| Cable Length: | 2.0 Meters | Interface: | HR10A-10R-12R |
| Connector: | HR10A-10P-12S | Feature: | High Flex,Chain Flex |
| Standard: | CE/ROHS/FCC/SGS | Type: | Overmolded |
Power/Trigger/Strobe Cable for GigE cameras with Hirose connector HR10A-10P-12S to Flying Leads 2meters
Description:
Analog video cables :
Connector "A" HR10A-10P-12S original and alternative connector available
Open end option for end "B" denotes flying leads for cable.
Cable type 24 AWG x 12C (I/O) is only available to flying leads (X).
Customer specified pin-out/color code for flying leads.
Connector Orientation: Right Angle options 1-8 are only available for end types 12 Pin Female Plug, 12 Pin Male Plug, 6 Pin Female Plug & 6 Pin Male Plug.
Connector A options,straight type and right angle type for options:
12 Pin Female Plug HR10A-10P-12S,12 Pin Male Plug HR10A-10P-12P,12 Pin Female Jack HR10A-10J-12,12 Pin Male Jack HR10A-10J-12P,6 Pin Female Plug HR10A-7P-6S,6 Pin Male Plug HR10A-7P-6P,8 Pin Female Plug HR25-7TP-8S,8 Pin Male Plug HR25-7TP-8P:
Specifications:
Available in different length: 2m, 5m, 10m
12 Pin Hirose connector (HR10A-10P-12S)
For all Photonfocus MV1 GigE cameras
Cable specifications:
Physical | Cable Color | Black |
Connector | HR10A-10P-12S | |
Jacket Material | PVC | |
Shell Material | Polyester Elastomer | |
Shell Color | Black | |
Shell Construction | Pre mold in Poly Ethelene wrapped 360 degrees with copper tape terminated to shield, overmolded in black PVC. | |
Cable construction | 24AWG*12C+DRAIN+AL/MAYLOR OD6.5MM BLACK PVC JACKET UL2464 | |
Electrical | Voltage Rating | DC 300V 0.08sec |
Current Rating | 1A | |
Insulation Resistance | 20 Mohm MIN | |
Dielectric Test | 3ohm Max | |
Temperature Rating | - 20 to +75 Celsius degree | |
Features:
1, Supports all HR10A-10R-12P(73) receptacle.
2, CHAIN FLEX/HIGH FLEX CABLE ATTIBUTION. Designed for high-performance vision applications
3, Full shielded.High performance anti-interference
4, All connector Over Molded PVC
5, Entire cable bundle shielded with foil and Coaxial for signal protection.
6, Trigger signals and power cord
7, 0.5meter to 5meters lengths available
8, Straight connection and Right angle available
9, Cables can be customized for specified requirements
10, High flex cable and standard cable available
11. FLEX test term: Locomotive track Flex Radius Flex Speed
Applications:
Indutrial Camera | DALSA,BASLER,SONY,COGNEX,CORECO,ADIMEC,EURESYS,JAI,IMPMEX,MATROX, DTA,PULNIX,EVISION,PLEORA,TOSHIBA TELI,NATIONALINSTRUMENT,REDLAKE,UNIQ,IDT,DVC,SILICONIMAGING,OMRON,PELCO, SENTECH,EPIX |
Imaging frame grabber | SONY,CORECO,EPIX,EURESYS,FORESIGHT,MATROX,EVISION,NATIONAL INSTRUMENT |
Machine vision | For all Camera Link standard interface |
Equipment Systems | Automatic Optical Inspection system(AOI), Mould monitor, Robot device,Machine Arms,Medical Equipment,Factory Equipment |
Competitive Advantage:
1, OEM SERVICE
2, GOOD QUALITY,HIGH FLEX,CHAIN FLEX CABLE
3, GOOD PRICE
4, SHORT TIME DELIVERY TIME
5, NICE SERVICE
6, 1YEAR GUARANTEE
